Explosion-proof display touch control all-in-one machine operating environment

Explosion-proof display plays an important role in dangerous places. It is one of the necessary displays in inflammable and explosive areas, such as: explosion-proof computer, industrial touch control all-in-one machine, explosion-proof operation table, explosion-proof display screen, etc. Our production of explosion-proof display is guaranteed, a relative national certification, strictly in accordance with the explosion-proof standards, including IEC60079 and EN60079, fast transportation, convenient installation!

Scope of application:

Suitable for explosive gas environment zone 1, zone 2 dangerous places;

Suitable for IIA, IIB, IIC grade explosive gas environment;

Applicable to combustible dust environment zone 20, zone 21, zone 22;

Suitable for temperature group T1~T6 environment;

Applicable to petroleum, petrochemical, chemical, brewing, medicine, paint, textile, printing and dyeing, facilities and other explosive dangerous environment;

Product features:

This product built-in international famous brand high resolution high bright LED inner screen, imported panel;

Integrated military motherboard, high temperature resistance, cold resistance can be year-round uninterrupted work;

With independent intellectual property rights convenient water cooling type integrated cooling design;

Instrument table design is ergonomic and easier to operate;

The shell is welded with high quality stainless steel material, and the whole is smooth and clean.

Multi-directional support for all kinds of industrial control interface;

External stainless steel metal explosion-proof waterproof keyboard;

The inlet and outlet line interfaces are made of stainless steel explosion-proof granulated head, or the user's own steel pipe or explosion-proof hose;

The shell has excellent anti-corrosion, dust-proof, waterproof and other properties;

The proportion of industry-leading screens (the higher the proportion of screens, the more difficult the production, the better the experience);

Product parameters:

Explosion-proof grade: Ex nR IIC T4 Gb (can be customized);

Protection level: IP65;

Configuration: Industrial motherboard /i3 processor /4GB memory /1TB hard disk/explosion-proof water-cooled system/stainless steel keyboard (multi-touch capacitive touch screen);

Platform support: Windows7/8/10, XP android;

Operation mode: explosion-proof keyboard + explosion-proof mouse/capacitive touch;

Brightness: 300cd/㎡;

Shell material: carbon steel spray/aluminum alloy/stainless steel 304;

Installation mode: wall-mounted/hoisting/vertical;
